RPU160 Reversible Pump by Simrad
0.SIMRAD RPU160 REVERSIBLE PUMP 21118237. RPU160 Drive UnitHydraulic steering methods at the moment are being used in every class of small vessel. In many admires hydraulic steerage is ultimate to mechanical steering. Hydraulic programs most often contain of two major components, a guidance wheel pump and guidance cylinder(s). The steerage wheel pump may be either a gear pump or a plunger pump. Which ever kind is installed, guidance is finished via fliping the guidance wheel in either course inflicting oil from the wheel pump to be equipped to the precise aspect of the cylinder. Oil is again by the use of the other side of the cylinder again to the pump.The linear motion of the cylinder rod is remodeled to a rotary motion by way of the tiller, which turns the rudder shaft and rudder. Check valves (non-return valves) are usually integrated to prevent the rudder riding the guidance wheel pump. If an autopilot is to be blanketed in the sort of hydraulic steerage device, then the oil drift offering the rudder movement must be controlled by means of electrical indicators from the autopilot. The most float rate of RPU160 is 1.6 l/min recognizeively, measured at a drive of 10 bar with nominal voltage (12vdc) on the motor terminals.. ... Read more RPU160 Reversible Pump
